1FL6092-1AC61-2AA1 V90 PN=3.5 KW NN=2000RPM MN=16.7 NM 3AC INC (KAMALI - FRENSİZ) SH90

SIMOTICS S-1FL6-1FL6 Operating voltage 3AC 400 V PN=3.5 kW; NN=2000 rpm, M0=22 Nm; MN=16.7 Nm Shaft height 90 mm, with angle connector; Incremental encoder 2500 incr./rev. with feather key, tolerance N without holding brake degree of protection IP65 with sealing ring compatible with the converters SINAMICS V70&V90

Product

• Article Number (Market Facing Number): 1FL6092-1AC61-2AA1
• Product Description: SIMOTICS S-1FL6-1FL6 Operating voltage 3AC 400 V PN=3.5 kW; NN=2000 rpm, M0=22 Nm; MN=16.7 Nm Shaft height 90 mm, with angle connector; Incremental encoder 2500 incr./rev. with feather key, tolerance N without holding brake degree of protection IP65 with sealing ring compatible with the converters SINAMICS V70&V90
• Product family: 1FL6 servomotors for SINAMICS V90
• Product Lifecycle (PLM): PM400:Announcement of product phase-out
• PLM Effective Date: Product phase-out since: 01.10.25

Delivery information

• Export Control Regulations: AL : N / ECCN : N
• Standard lead time ex-works: 5 Day/Days
• Net Weight (kg): 19.800 Kg
• Packaging Dimension: 365.00 x 495.00 x 340.00
• Package size unit of measure: MM
• Quantity Unit: 1 Piece
• Packaging Quantity: 1

Additional Product Information

• EAN: 4042948675137
• UPC: 804766790607
• Commodity Code: 85015220
• LKZ_FDB/ CatalogID: NC81
• Product Group: 5183
• Group Code: R220
• Country of origin: China
• Compliance with the substance restrictions according to RoHS directive: Since: 01.01.18
• Product class: C: products manufactured / produced to order, which cannot be reused or re-utilized or be returned against credit.
• WEEE (2012/19/EU) Take-Back Obligation: Yes
• REACH Art. 33 Duty to inform according to the current list of candidates: Reach Information Information according REACH Article 33(1) on svhc candidate substances (substances of very high concern http://echa.europa.eu/web/guest/candidate-list-table) for configured products will be provided with the order confirmation and bill of delivery. Information is available only if a duty to inform for the configured product applies.
