1PH8288-1HC40-1BU2 M COMPACT ASYNCHRONOUS MOTOR 700 RPM, 272 KW

SIMOTICS M compact asynchronous motor 700 r/min, 272 kW, 3711 Nm, 570 A, 325 V 800 r/min, 310 kW, 3701 Nm, 560 A, 370 V 1000 r/min, 385 kW, 3677 Nm, 560 A, 460 V open-circuit ventilation degree of protection IP23 Incremental encoder HTL 1024 S/R (encoder HTL1024S/R) with temperature sensor Pt1000 DESIGN IM B3 (IMV6) SHAFT WITH FITTED KEY FULL-KEY BALANCING BEARING: STANDARD VIBRATION SEVERITY GRADE R/A; SHAFT A.FLANGE ACCURACY GR. R TERMINAL BOX (ABOVE) CABLE ENTRY BELOW SIGNAL CONNECTION D-END

Product

• Article Number (Market Facing Number): 1PH8288-1HC40-1BU2
• Product Description: SIMOTICS M compact asynchronous motor 700 r/min, 272 kW, 3711 Nm, 570 A, 325 V 800 r/min, 310 kW, 3701 Nm, 560 A, 370 V 1000 r/min, 385 kW, 3677 Nm, 560 A, 460 V open-circuit ventilation degree of protection IP23 Incremental encoder HTL 1024 S/R (encoder HTL1024S/R) with temperature sensor Pt1000 DESIGN IM B3 (IMV6) SHAFT WITH FITTED KEY FULL-KEY BALANCING BEARING: STANDARD VIBRATION SEVERITY GRADE R/A; SHAFT A.FLANGE ACCURACY GR. R TERMINAL BOX (ABOVE) CABLE ENTRY BELOW SIGNAL CONNECTION D-END
• Product family: 1PH8 for SINAMICS S120 for production machines
• Product Lifecycle (PLM): PM300:Active Product

Delivery information

• Export Control Regulations: ECCN : N / AL : N
• Standard lead time ex-works: 35 Day/Days
• Net Weight (kg): 1650.000 Kg
• Package size unit of measure: Not available
• Quantity Unit: 1 Piece
• Packaging Quantity: 1

Additional Product Information

• EAN: Not available
• UPC: Not available
• Commodity Code: 85015381
• LKZ_FDB/ CatalogID: SD.NC62ST-1PH8
• Product Group: 9694
• Group Code: R220
• Country of origin: Czech Republic
• Compliance with the substance restrictions according to RoHS directive: Since: 21.07.19
• Product class: D: products made to order / customer's specifications, requiring engineering services, which cannot be re-used or utilized (design to customer)
• WEEE (2012/19/EU) Take-Back Obligation: Yes
• REACH Art. 33 Duty to inform according to the current list of candidates: Reach Information Information according REACH Article 33(1) on svhc candidate substances (substances of very high concern http://echa.europa.eu/web/guest/candidate-list-table) for configured products will be provided with the order confirmation and bill of delivery. Information is available only if a duty to inform for the configured product applies.
