6ES7522-5HH00-0AB0 S7-1500 DI 16 x 230V AC/2A RELAY ST

SIMATIC S7-1500, digital output module DQ 16x 230V AC/2A ST; relay 16 channels in groups of 2; 4 A per group; switching cycle counter for integrated relay, diagnostics; substitute value: the module supports the safety-oriented shutdown of load groups up to SIL1 according to EN IEC 62061:2021 and Category 2 / PL c according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately

Product

• Article Number (Market Facing Number): 6ES7522-5HH00-0AB0
• Product Description: SIMATIC S7-1500, digital output module DQ 16x 230V AC/2A ST; relay 16 channels in groups of 2; 4 A per group; switching cycle counter for integrated relay, diagnostics; substitute value: the module supports the safety-oriented shutdown of load groups up to SIL1 according to EN IEC 62061:2021 and Category 2 / PL c according to EN ISO 13849-1:2015. front connector (screw terminals or push-in) to be ordered separately
• Product family: SM 522 digital output modules
• Product Lifecycle (PLM): PM300:Active Product

Delivery information

• Export Control Regulations: AL : N / ECCN : N
• Standard lead time ex-works: 1 Day/Days
• Net Weight (kg): 0.369 Kg
• Packaging Dimension: 15.10 x 15.10 x 4.70
• Package size unit of measure: CM
• Quantity Unit: 1 Piece
• Packaging Quantity: 1

Additional Product Information

• EAN: 4047623404187
• UPC: 804766137877
• Commodity Code: 85389091
• LKZ_FDB/ CatalogID: ST73
• Product Group: 4501
• Group Code: R135
• Country of origin: Germany
• Compliance with the substance restrictions according to RoHS directive: Since: 11.03.15
• Product class: A: Standard product which is a stock item could be returned within the returns guidelines/period.
• WEEE (2012/19/EU) Take-Back Obligation: Yes
• REACH Art. 33 Duty to inform according to the current list of candidates: Lead CAS-No. 7439-92-1 > 0, 1 % (w / w) Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): Lead Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. Lead monoxide (lead ... CAS-No. 1317-36-8 > 0, 1 % (w / w) Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): Lead monoxide (lead oxide) Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. 2-methyl-1-(4-methyl... CAS-No. 71868-10-5 > 0, 1 % (w / w) Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): 2-methyl-1-(4-methylthiophenyl)-2-morpholinopropan-1-one Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. 4,4'-isopropylidened... CAS-No. 80-05-7 > 0, 1 % (w / w) Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): 4,4'-isopropylidenediphenol (Bisphenol A, BPA) Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation. Silicic acid, lead s... CAS-No. 11120-22-2 > 0, 1 % (w / w) Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): Silicic acid, lead salt Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.
